CJX2 AC Contactors

Submit Comments
*Name
Phone
*Email
Address
*Message

1.Application
CJX2 series AC Contactor is suitable for using in the circuits up to the rated voltage 660V AC50Hz or 60Hz, rated current up to 620A, for making, breaking, frequently starting & controllingthe AC motor. Combined with the auxiliary contact block, timer delay & machine-interlockingdevice etc, it becomes the delay contactor, mechanical interlocking contactor, star-delta starter.With the thermal relay, it is combined into the electromagnetic starter. The product conforms toIEC60947-4-1 stardand.


2. Specification

TypeCJX2-D09CJX2-D12CJX2-D18CJX2-D25CJX2-D32CJX2-D40CJX2-D50CJX2-D65CJX2-D80CJX2-D95
Rated workingcurrent (A)AC39121825324050658095
AC43.557.78.51218.524283744
Standardpower ratingsof 3-phasemotors50/60Hz incategory AC-3220/230V2.2345.57.5111518.52225
380/400V45.57.5111518.522303745
415V45.5911152225374545
500V5.57.5101518.52230375555
660/690V5.57.5101518.53033374555
Rated heat current (A)2020324050608080125125
Electrical lifeAC3 (x104)100100100100808060606060
AC4 (x104)20202020201515151010
Mechanical life (x104)1000100010001000800800800800600600
Number of the contacts3P+NO3P+NC+NO
3P+NC



TypeCJX2-D115CJX2-D150CJX2-D170CJX2-D205CJX2-D245CJX2-D300CJX2-D410CJX2-D475CJX2-D620
Rated workingcurrent (A)AC3115150170205245300410475620

AC452607585105117138147180
Standard powerratings of 3-phase motors50/60Hz incategory AC-3220/230V3040556375100110147200
380/400V557590110132160220265335
415V5980100110132180220280375
500V7590110129160200250355400
660/690V80100110129160220280355450
Rated heat current (A)2002502502753154005007001000
Electrical lifeAC3 (x104)2006060505050303020
AC4 (x104)151515151515885
Mechanical life (x104)300300300300300300300100100100



3. Standard Control Circuit Voltage

Volts244248110220230240380400415440500600
50HzB5D5E5F5M5P5U5Q5V5N5R5S5Y5
60HzB6D6E6F6M6-U6Q6--R6--
50/60HzB7D7E7F7M7P7U7Q7V7N7R7--
